Name: 120kW Rated Output Methanol Fuel Cell Generator with Zero-Emission Clean Energy and Ultra-Low Electricity Cost
Brand: JoShining Energy & Technology Co.,Ltd
SKU: X120-1
Price: 700,001.00 USD
Availability: InStock

ホーム > 製品 > メタノールの割れること >

120kW Rated Output Methanol Fuel Cell Generator with Zero-Emission Clean Energy and Ultra-Low Electricity Cost

起源の場所:

中国

ブランド名:

Joshining

証明:

モデル番号:

X120-1

お問い合わせ

見積もりをリクエストしてください

120kW Rated Output Methanol Fuel Cell Generator with Zero-Emission Clean Energy and Ultra-Low Electricity Cost

製品の詳細

定格出力電力:

120kW @ 380V AC

燃料仕様:

62 ~ 63 wt% メタノール-水溶液、0.66 kg メタノール/kWh、130 kg 溶液/h

燃料電池モジュール:

150kW スタックを備えた独自の低温 PEMFC システム

エネルギー貯蔵モジュール:

96 kWh ニッケル亜鉛 (Ni-Zn) またはリン酸鉄リチウム (LFP) バッテリー

冷却システム:

独自の高度に統合された熱管理センター

環境的側面:

4.1×2.5×2.8m

支払いと送料の条件

最小注文数量

価格

negotiable

パッケージの詳細

木箱

受渡し時間

30-60日

支払条件

LC、T/T

供給の能力

100

99%-99.9999% 純度のメタノールの割れる水素の世代別単位

最もよい価格を得なさい

ベルタイプ炉のアニーリングのための水素の生産のメタノールの割れるシステム

最もよい価格を得なさい

低温高圧メタノールクラッキング保護ガス炉

最もよい価格を得なさい

保護ガス溶液メタノールクラッキング水素発電機先進技術による

最もよい価格を得なさい

お問い合わせ

今すぐ連絡

製品説明

High-Efficiency Methanol Fuel Cell Generator 2.5kW-120kW

Methanol Fuel Cell Generator System (FCS) represents the next generation of clean energy technology. By seamlessly integrating advanced methanol steam reforming with high-performance proton exchange membrane fuel cells (PEMFC), this system converts a methanol-water mixture directly into stable, eco-friendly electricity. Whether you need a compact backup power source or the world's largest 120kW rated output for industrial, grid-connected, or vehicular applications, this system delivers unrivaled efficiency and economic value.

Key Features & Technical Capabilities

World-Leading 120kW Rated Output: Providing the largest rated output capacity globally for methanol-to-hydrogen power generation
Ultra-Low Electricity Cost: Achieve exceptional economy with optimized electricity costs
True Zero-Emission Clean Energy: Green energy profile with absolute zero emissions of SOx, NOx, and Particulate Matter (PM)
Flexible Operational Modes: Fully capable of independent off-grid operation or seamless integration into vehicular applications and grid-connected systems
Long-Endurance Continuous Run: Equipped with a standard 1m³ (1t) fuel tank, the 120kW system can continuously power your operations for 8 hours at rated load

Core Technology Architecture & Working Principle

FCS utilizes a proprietary closed-loop system designed for maximum thermal and electrochemical efficiency.

Methanol Reforming & Hydrogen Production: A fuel mixture of methanol and demineralized water goes into the reformer, utilizing waste heat and steam to produce hydrogen efficiently
Hydrogen Purification: The generated gas passes through proprietary purification technology to deliver high-purity hydrogen
Fuel Cell Integration: The pure hydrogen combines with ambient air in the highly integrated PEMFC system to output reliable, stable electrical power

Technical Specifications & Product Parameters

Parameter / Model	Poseidon-LT-2.5	Poseidon-LT-10	Poseidon-LT-50	Poseidon-LT-100
Power Output	2.5 kW	10 kW	50 kW	100 kW
System Output Voltage	48 VDC or 220 VAC (Highly adaptable for telecom/backup)
Fuel Composition	59-61 wt.% Methanol Demineralized Water
Methanol Consumption	0.6 kg/kWh
System Efficiency	40%
System Lifespan	20,000 hours
Acoustic Noise Level	< 65 dB @ 1m (Ultra-silent operation)
Ambient Temperature	-10°C to 55°C
Dimensions & Weight	1150 * 600 * 1200 mm / Weight: 200 kg

Why Partner with Joshining?

We possess full core competencies across Hydrogen Generation Reforming, Hydrogen Purification, and Fuel Cell System Integration.

Highly Modularized Engineering: Every high-power unit integrates an advanced Hydrogen Buffer Tank, Hydrogen Generation Module, Fuel Cell Module, Energy Storage Module, and Electrical Control Module into a single robust frame for rapid plug-and-play deployment
Substantial Operational Savings: Lower your total cost of ownership (TCO) with high-efficiency output and fuel consumption optimized to the absolute physical limits
Global Export Capability: Built to comply with strict international industrial and electrical standards, making it the ideal clean energy upgrade for global markets

What are the primary emissions of this methanol-to-hydrogen system?

This is an exceptionally clean power solution. The chemical process results in zero SOx, zero NOx, and zero Particulate Matter (PM), making it ideal for environmentally sensitive regions, urban zones, or indoor industrial setups.

Get a Tailored Clean Energy Quote Today!

Looking to replace polluting diesel generators, reduce grid electricity costs, or integrate clean fuel cell power into your commercial fleet? Our engineering team is ready to customize the system to match your precise voltage and power requirements.
